Full Description
Overwound for more low end response, the Duke delivers more punch and thickness to your Jazz Bass. Scatterwound coils on fully charged Alnico 5 polepieces allow for an increased output - making the Duke the perfect "Vintage Modern" set.
Wax potted to eliminate microphonic feedback. RWRP for noise cancelling operation when both pickups are in series or parallel.
The Duke J is available with flat or staggered polepieces. Staggered polepieces work especially well with basses with more rounded fingerboards, such as the 7 1/4" radius boards found on vintage models and reissues.
Tech Specs
| The Duke Neck | The Duke Bridge | |
|---|---|---|
| Model | J2N | J2B |
| Magnet | Alnico 5 Rod | Alnico 5 Rod |
| DCR | 8.2k | 9.5k |
| Inductance | 3.9H | 5.0H |
| Hookup Wire | Vintage Braid | Vintage Braid |
| Winding Direction | Counter-Clockwise | Clockwise |
| Polarity | South Pole Up | North Pole Up |
Dimensions
Wiring Diagrams
